Custom Multi-Hole Vacuum Chuck for Versatile CNC Machining

Product Description:

Our custom multi-hole vacuum chucks provide a highly adaptable and efficient workholding solution for CNC machining centers and CNC milling machines. Designed for maximum versatility, these chucks feature a grid of multiple vacuum ports, allowing for secure clamping of workpieces with various shapes, sizes, and footprints. This customizable solution ensures optimal holding force and stability for a wide range of machining operations, enhancing accuracy and productivity.

Key Features:

Customizable Design: Tailored to your specific CNC machine table dimensions and workpiece requirements, including the number and placement of vacuum holes.
Multi-Hole Grid System: Offers exceptional flexibility in fixturing various workpiece shapes and sizes.
Independent Vacuum Zones (Optional): Allows for the activation and deactivation of specific vacuum areas to accommodate different workpiece layouts and maximize holding force.
Secure and Uniform Clamping: Distributes vacuum evenly across the workpiece surface for a firm and stable hold, minimizing vibration.
Adaptable to Various Materials: Effectively secures ferrous and non-ferrous metals, plastics, composites, wood, and more.
Reduced Setup Times: Quick and easy workpiece loading and unloading by utilizing strategically placed vacuum ports and sealing materials.
Minimized Clamping Interference: Enables machining on multiple sides of the workpiece without repositioning traditional clamps.
Damage-Free Workholding: Eliminates the risk of workpiece deformation or scratching associated with mechanical clamping.
Durable Construction: Engineered with high-quality materials for long-lasting performance in demanding machining environments.

Specifications

Specification	Magnetic attraction	Width (mm)	Length (mm)	Height (mm)	Weight (kg)
150*150	≥40KG	150	150	80	13.5
150*300	≥40KG	150	300	80	27
150*350	≥40KG	150	350	80	31.5
150*400	≥40KG	150	400	80	36
200*200	≥40KG	200	200	80	24
200*300	≥40KG	200	300	80	36
200*400	≥40KG	200	400	80	48
200*500	≥40KG	200	500	80	60
250*500	≥40KG	250	500	80	75
300*300	≥40KG	300	300	80	54
300*400	≥40KG	300	400	80	72
300*500	≥40KG	300	500	80	90
300*600	≥40KG	300	600	80	108
300*800	≥40KG	300	800	80	144
400*400	≥40KG	400	400	80	96
400*500	≥40KG	400	500	80	120
400*600	≥40KG	400	600	80	144
400*800	≥40KG	400	800	80	192
500*500	≥40KG	500	500	80	150
500*600	≥40KG	500	600	80	180
500*800	≥40KG	500	800	80	240
600*800	≥40KG	600	800	80	288
600*1000	≥40KG	600	1000	80	360

Applications:

Precision milling and engraving
High-speed machining of various materials
Securing complex and irregularly shaped workpieces
Machining of thin or delicate parts
Prototyping and small to medium batch production
Automation and robotic loading/unloading

Benefits:

Achieves high machining accuracy and superior surface finish.
Improves production efficiency through faster setup and cycle times.
Offers exceptional flexibility in fixturing diverse workpiece geometries.
Reduces workpiece damage and scrap rates.
Provides a secure and stable hold for demanding operations.
Simplifies fixturing for complex parts.
Enhances safety during machining processes.

Why Choose Us:

We specialize in providing high-performance and custom vacuum workholding solutions for CNC machining centers and milling machines. Our multi-hole vacuum chucks are engineered for maximum versatility and precision. Our experienced team can design and manufacture solutions tailored to your specific machining needs, offering competitive pricing and excellent technical support. Located in Dongguan, Guangdong Province, China, we are ready to serve your global manufacturing needs.
